Original price was: $55.00.$49.90Current price is: $49.90.
The IN-12A has 12 pins. Pin 1 is the anode.
This pin is tied to 170-200V DC. Pins 2-11 are the individual number cathode pins.
When you want to illuminate a particular number, place 0V on the corresponding cathode pin (be sure to include a current limiting resistor on the anode pin).
| Type | IN-12A | |
| Brand | Gazotron | |
| Substitudes | IN-12A (with PL) | |
| displayed Symbols | 0-9 | |
| Symbol Height | 18 | mm |
| Length x Width | 21 x 32 | mm |
| Total Height | 35 | mm |
| Pin Diameter | 1.02 | mm |
| Typical Plate Voltage | ca./approx. 145 | V |
| Typical Cathode Current | 2.5…3.5 | mA |
| Base | SK-136 | |
| Socket | SK-136 or Pin Receptacles 1mm | |
