🔊What is a 6P45S Amplifier Tube?
6P45S tube definition is four-electrode vacuum electronic tube (output beam tetrode ). Used primarily in audio amplifiers.
🔍Looking for EL509 Tube equivalent for Affordable Price?
Visit our Store on
📈6P45S tube Plate-grid and plate curves
🎼EL519 VS 6P45S
You can use 6P45C as a el519 tube equivalent, although it’s important to note that doing so may prevent you from reattaching the cover on your radio or amplifier.
💡EL509 VS 6P45S
The 6P45S tube is a direct analogue of the EL509 / 6KG6 tubes.
🎚️6P45S Tube Equivalent
- 6KG6A,
- 6N45S,
- 6P45C,
- 6P45S,
- EL509,
- EL519,
- 8704
🏭6P45S Tube Manufacturers:
Reflector Factory (Extremely rare tubes)
Ulyanovsk
Svetlana Factory (common version)
The 6P45S tubes produced by Svetlana are generally well adapted for use in amplifiers. Svetlana is a well known manufacturer for producing highly reliable vacuum tubes.
💸Average Price:
→ What Is The Average Price for 6P45S Tube?
The average price of an 6P45s tube is $20 USD
→ What is the average price for EL509 tube?
The average price for a new EL509 tube ranged from $30 to $60 USD
→ What is the average price of an EL519 tube?
The average price of an EL519 tube ranged from $60 to $100 USD
📊6P45S Datasheet:
| Name | 6P45S |
| Type | Output beam tetrode |
| Application | Application in output stages of TV scan modules |
| Cathode type | oxide,indirect heating |
| Envelope | glass |
| Mass,g | 140 |
| Filament voltage,V | 6,3 |
| Filament current,A | 2,3-2,7 |
| Anode voltage,V | 50 |
| Anode current,A | 0,8 in pulse |
| Anode power,W | 35 |
| Grid1 voltage,V | minus 10 |
| Grid2 voltage,V | 175 |
| Reverse grid current,uA | 2 |
🛒Looking for a trusted seller of 6P45S tubes?
- We have many variations of 6P45S tubes (different conditions and years of manufacture).
- We’ve been helping our customers enjoy pure sound for years!
- We’ll find the right amount for you, combine the add-on, and help you with all levels of the transaction!
